UniFi Protect: the equipment behind a camera installation
A surveillance system combines cameras, networking, power and recording capacity.
What the image shows
The photograph brings together UniFi equipment boxes and an infographic relating cameras, a switch, a gateway and mounting accessories. It is a component reference, not confirmation of exact models or capacity.
How the pieces connect
In a compatible installation, a PoE switch supplies network connectivity and power to cameras. The system needs a Protect-compatible console or recorder and storage sized for the recording requirements.
What to decide before buying
Define the camera count, positions, coverage areas and desired retention time. Review the PoE budget, cable routes and compatibility of each model. The trademarks shown belong to their respective owners.
